Toro Dingo TX 427 Wide Track

[ Enter your text here. ]

Toro Dingo TX 427 Wide Track Features:

Engine Kohler Command Pro Series 27 horse power Air Filter Cooling System Fuel Tank Oil Capacity

Hydraulic System Pressure Flow

Reservoir Capacity Auxiliary Horsepower

Track Standard

Track Drive Standard

Traction

Two-Stage, heavy duty, remote Air Cooled 6 gallons 2 quarts

Standard Endless Kevlar reinforced rubber, 96.6" x 9.5", single internal tooth drive

Sprocket drive, 10 road wheels per side, cast iron track guide Dual hydrostatic pump

3000 psi 11.4 gpm auxillary, 6 gpm loader arm, 16.9 gpm traction for each traction pump 10.5 gallons 20 horsepower

Toro Dingo TX 427 Wide Track Specifications:

Dimensions

Track Width (A) Wheelbase (B) Ground Clearance (C) Overall Length Overall Width (D) Overall Height (E) Maximum Operating Height (F) Hinge Pin Height (G) Dump Height (H) Dump Angle (I) Reach Ground Speed

Tip Capacity SAE J818 Rating 50% tip capacity SAE J818 Rating 35% tip capacity Weight with standard bucket Weight with out standard bucket Ground Pressure

9.5" 31.2" 4.6" 92" with bucket 70.7" without bucket 41" 46.1" 90.1" 65.8" 46.1" 38 degrees 21.8" fully raised 0-4.5 mph forward 0-2 mph reverse 1530 lbs 765 lbs 535 lbs 2186 lbs 2075 lbs 3.5 psi

use diagram above and match to the corresponding letter

CALL TO BUY OR FOR A DEMO 703 919 1379 We Can Ship The Toro Dingo 427 Wide Track To You Anywhere in the United States or Canada

Financing programs available like $0 down and no payments for 120 days and 0 percent interest for 42 months. Other programs available too!

No sales tax charged on 427 wide tracks shipped outside the state of Virginia

Please click here for even more information on the Toro Dingo TX 427 Wide Track

E&S Equipment, LLC 6799 Kennedy Road Suite E Warrenton VA 20187 (703) 919-1379 www.esequipmentllc.com
