Toro Dingo 323

Toro Dingo 323 Features:

Engine  Kohler Command Pro 23 horse power Air Filter  Cooling System  Fuel Tank  Oil Capacity

Hydraulic System Pressure Flow

Reservoir Capacity

Two Stage, heavy duty, remote air cleaner Air Cooled 8 gallons 2 quarts

3250 psi 4 gpm low flow hydraulic circuit, 10.8  gpm high flow hydraulic circuit 14.8 gallons

Toro Dingo 323 Specifications

Dimensions (A)  Wheelbase                       (B)  Ground Clearance                (C)  Overall Length                       Overall Width                    (D)  Overall Height                    (E)  Maximum Operating Height          (F)  Hinge Pin Height                 (G)  Dump Height                    (H)  Dump Angle                     (I)   Reach                     Ground Speed                 Tip Capacity                         SAE J818 Rating 50% tip capacity      Weight with standard bucket            Weight with out standard bucket

28" 5.8" 62" without bucket              82.2" with bucket                  40.5" with standard tires           48.7" 91.2"                  66"                   47" 34 degrees                    28" fully raised                 0-4.5 mph forward and reverse 1030 lbs                       515 lbs     1713 lbs     1567 lbs

use diagram above and match to the corresponding letter

CALL TO BUY OR FOR A DEMO  703 919 1379 We Can Ship The Toro Dingo 323 To You Anywhere in the United States or Canada

Financing programs available like $0 down and no payments for 120 days and 0 percent interest for 42 months.  Other programs available too!

No sales tax charged on any Toro Dingo 323 shipped outside the state of Virginia

Please click here for even more information on the Toro Dingo 323
